ISO9001 Certified Galvanized Steel Stair Treads with Perforated Metal for Pedestrian Traffic

Galvanized Steel Grating, is extremely strong and durable for all load bearing applications and is primarily used for pedestrian and light vehicle traffic. Our galvanized coating process provides for years of corrosion resistance in acidic and high moisture environments.

Galvanized Steel Expanded Metal is a sheet product that has been slit and stretched to diamond shaped openings. Galvanized expanded metal offers savings in weight and allows free passage of light, liquid, sound and air while providing corrosion resistance in harsh environments.

GLOSSARY OF TERMS
1. Bearing Bar - Loading carrying bars made from steel strip or slit sheet or from rolled or extruded aluminum, extending in the direction of the grating span.
2. Cross Bar - The connection bars, made from steel strip, slit sheet or rolled bars or from rolled or extruded aluminum, which extend across the bearing bars, perpendicular to them. They're bent into a corrugated or sinuous pattern. Where they intersect the bearing bars, welded, forged or mechanically locked to bearing bars.
3. Bearing Bar Centers - The distance center to center of the bearing bars.
4. Cross Bar Centers - The distance center to center of the cross bars.
5. Band - A flat welded to a side or end of grating panel. Or along the line of a cutout, extending neither above nor below bearing bars.
6. Toe Plate- Also called kick plate. A flat bar attached flat against the outer edge of grating or rear edge of tread. Projecting above the top surface of grating or tread to form a lip or curb.
7. Length - Refer to span of grating.
8. Width - The overall dimension of grating panel. Measured normal to the bearing bars.

Application
- Grating floor mat
- Working platform
- Grating floor panels
- Grating manhole cover
- Grating ditch cover
- Stairs, stairs Grating
- Traffic works, highways, factories, farms, urban areas
- Oil and gas industries, cement, ships...

Conventional Grating Specifications
Bear Bar(mm)	Cross Bar(mm)			Bearing Bar Spacing(mm)	Cross Bar Spacing(mm)	Width(mm)	Length(mm)
20x3	5x5	6x6	8x8	30*34*40	38*50*100	993	6000 or custom
20x5	5x5	6x6	8x8	30*34*40	38*50*100	995	6000 or custom
25x3	5x5	6x6	8x8	30*34*40	38*50*100	993	6000 or custom
25x5	5x5	6x6	8x8	30*34*40	38*50*100	995	6000 or custom
30x3	5x5	6x6	8x8	30*34*40	38*50*100	993	6000 or custom
30x5	5x5	6x6	8x8	30*34*40	38*50*100	995	6000 or custom
32x3	5x5	6x6	8x8	30*34*40	38*50*100	993	6000 or custom
32x5	5x5	6x6	8x8	30*34*40	38*50*100	995	6000 or custom
40x3	5x5	6x6	8x8	30*34*40	38*50*100	993	6000 or custom
40x5	5x5	6x6	8x8	30*34*40	38*50*100	995	6000 or custom
50x3	5x5	6x6	8x8	30*34*40	38*50*100	993	6000 or custom
50x5	5x5	6x6	8x8	30*34*40	38*50*100	995	6000 or custom
* The table is of regular specifications. If other models are required, we will customize them for customers.

Product Tags:

Perforated Metal Stair Treads



ISO9001 Galvanized Steel Treads



Pedestrian Traffic Metal Treads



ISO9001 Certified Galvanized Steel Stair Treads with Perforated Metal for Pedestrian Traffic Images
