Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads

  • 1
  • 2
  • 3

Brand Name : GNEE

Certification : SGS

Place of Origin : China

Price : Negotiable

Payment Terms : Negotiable

Supply Ability : 100 ton/week

Delivery Time : 5-9 working days

Packaging Details : Sea-worthy packing, ie wooden or steel tray with steel strip,etc

Contact Now

GNEE Steel specializing in the production of steel grating , steel grate and frame , trench grate , kerb grate ,storm pits cover , access cover grate , manhole covers.side entry grate , steel stair , steel ball stanchion , steel railing , aluminium grating and other light steel structure products The company has a complete computer-aided design system that can provide users with perfect steel grating layout design. The processing technology is superb and the product quality is excellent.

Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads

stair treads steel grating is made by bearing bar and cross bar according to the flat-steel weft arrangement, in high-pressure spacing on resistance welder welded by cutting, incision, opening, overlock process such as processing and into customer.

requirements finished products. It's usually used in industrial construction projects. We have 4 types for choose, there is welded
fixing stair treads, clip fixing galvanized stair treads, checker plate stair treads.

Name Stainless Steel Grating
Bearing Bar 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc
I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc
US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'', 1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1
1/2''x1/8'' etc
Bearing Bar Pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Twisted Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
Material Grade ASTM A36, A1011, A569, Q235, S275JR, SS304, SS400,
Mild steel & Low carbon steel, etc
Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating
Grating Style Plain / Smooth, Serrated /teeth, I bar, serrated I bar
Standard China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88),
UK: BS4592-1987, Australia: AS1657-1985,
Germany: DIN24537-1-2006, Japan :JIS

Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads

Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads

Metal Plank Grating Stair Treads/Grating Treads/Galvanized Steel Treads /Powder-Coated Steel Treads/Wide Range of Stair Treads
